Folding Table Leg Bracket Self Lock

Description

Folding Table Leg Bracket – Locking, Heavy Duty, Zinc Plated | AUSUJO

Short description
Heavy-duty locking folding leg bracket with quick release lever. Ideal for fold-away tables, benches, trestles, camper/RV fit-outs. Steel, zinc plated. Aussie seller • Experts in the trade • Fast dispatch from Melbourne (Australia Post with tracking).

Product overview
Build space-saving furniture that folds flat when not in use. This bracket locks the leg securely in the open position and folds with a simple lever pull. Multi-hole mounting plates make installation straightforward on timber aprons or frames.

Key features
• Locking mechanism — positive lock open; pull lever to fold
• Heavy-duty steel with zinc-plated (yellow passivated) finish
• Pre-drilled mounting holes for common timber screws/bolts (not included)
• Universal orientation — one per leg; pair for larger tops
• Smooth, rounded edges; protective cap on release lever

Important: Brackets can be easily opened and closed only after the legs are attached. When not attached to a leg, the lock is very stiff and difficult to fold by hand (by design).

Weight
• Approx. 131 g per bracket

Dimensions
• Open: 75 × 60 × 65 mm
– Suits legs 45 mm wide or larger (the side attached to the bracket)
• Closed: 75 × 32 × 65 mm
– The 32 mm figure indicates the gap between the tabletop and leg when folded

Type
Folding / flip-up table leg bracket, locking with release lever

Material & finish
• Material: Steel
• Finish: Zinc plated (yellow passivated)

Installation (general guidance)

1. Position the bracket under the top/apron; ensure lever access.

2. Mark and pre-drill pilot holes.

3. Fix with appropriate timber screws/bolts (not included).

4. Test lock/fold action before final tightening.

What’s included
• 1 × Folding table leg bracket (select quantity)

Shipping
• Fast shipping Australia-wide — Australia Post with tracking
• Same/next business day dispatch from Melbourne
• Pickup is not available
